Industrial-grade four-door one-way cloud service WAN access controller, is the latest developed WAN communication access control equipment, is a perfect combination of access control system and cloud technology, communication speed, high data security. The equipment is powerful, in addition to the characteristics of WAN communication, almost covers all the functions of the market access control needs. It is widely used in bank vaults, military, public security, government agencies, large group companies, enterprises and institutions with more terminal equipment and complex management levels across regional and regional networks.
| Motherboard size | 166*112mm |
| Communication mode | TCP/IP |
| Total record | 98000(Recyclable storage) |
| Card capacity | 25000 |
| Password capacity | Match with card |
| Control gate number | 4 |
| External card reader | 4 |
| External switch | 4个 |
| Card reader protocols are supported | WG34/26 |
| Distance from card reader to controller | Within 100 meters. 80 meters is recommended |
| Bundled software | Card management system5.0 |
| Supporting database | access and sql |
